Developed by: Technical Literature Cell. Release Date : Jan 2019/ First Edition. The information provided in this manual is based on the latest product information available at the time of publication. . C Copyright 2019 TATA MOTORS All rights reserved. The information in this manual shall not be reproduced or copied, in whole or in part, in any form without written permission from TATA MOTORS. Vehicles are subject to modification in design, specification and equipment. Also refer the Service Circulars released by Customer Support about product & procedures.
DIAGNOSTIC TROUBLE SHOOTING CODES
DIAGNOSTIC TROUBLE SHOOTING CODES INDEXX 1. ENGINE..........................................................................................................5 - 1084 2. INSTRUMENT CLUSTER ........................................................................ 1085- 11060 3. INFOTAINMENT ...................................................................................... 1107 - 1343 4. BCM ......................................................................................................... 1344 - 2935 5. ESCL........................................................................................................ 29360- 3033 6. ESP .......................................................................................................... 3034 - 3257 7. PEPS......................................................................................................... 3258- 3653 8. ABS..........................................................................................................3654 - 3807 9. FATC........................................................................................................3808- 4262 10 SRS.......................................................................................................... 4263 - 4818 11. IMMOBILIZER..........................................................................................4819 - 4910
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 1 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. Q5 Project – EMS ECU/Component Replacement Procedure Issue Date Author E-mail 0.1 24 Jul 2017 Shashank Addala Prasad M Shashank.Addala@tatatechnologies.com mvskprasad@tatamotors.com
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 2 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. A Document History Issue Date Author Release Status 0.1 24 July 2017 Shashank Addala / Prasad M 1st Draft Release
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 3 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. B Change History Version Page Section Change Details - - - -
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 4 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. TABLE OF CONTENTS A Document History ........................................................................................................................... 2 B Change History................................................................................................................................ 3 C List of Acronyms and Abbreviations................................................................................................. 5 1 Introduction .................................................................................................................................... 6 1.1 General Overview............................................................................................................................ 6 1.2 Scope of the Document ................................................................................................................... 6 1.3 Intended Audience.......................................................................................................................... 6 1.4 IPR Ownership................................................................................................................................. 6 1.5 Reference Documents ..................................................................................................................... 6 2 Project Applicability ........................................................................................................................ 6 3 EMS Replacement Procedure Flowchart .......................................................................................... 7 4 EMS ECU, Component Replacement Procedure ............................................................................... 8 4.1 ECM - Engine Control Module (In case of old ECM communicates) .................................................. 8 4.2 ECM - Engine Control Module (In case of old ECM doesn’t communicates).....................................10 4.3 Single injector ................................................................................................................................13 4.4 All the injectors ..............................................................................................................................14 4.5 Closed coupled DPF + DOC .............................................................................................................15 4.6 DPF pressure sensor .......................................................................................................................16 4.7 Electrical VGT position sensor ........................................................................................................17 4.8 Electrical VGT turbo compressor ....................................................................................................18 4.9 Engine oil replacement...................................................................................................................19 4.10 Rail pressure sensor .......................................................................................................................20 4.11 Regeneration forced............................................................................ Error! Bookmark not defined. 4.12 Air Flow meter ...............................................................................................................................21 4.13 Lambda sensor ...............................................................................................................................22 4.14 EGR high pressure DC Motor ..........................................................................................................23 4.15 Throttle Valve Actuator ..................................................................................................................24 4.16 Reset driven distance max Th2O warning lamp ON.........................................................................25 4.17 Reset driven distance H2O in fuel lamp ON ....................................................................................26 4.18 ECM PROGRAMMING.......................................................................... Error! Bookmark not defined.
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 5 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. C List of Acronyms and Abbreviations S No. Acronyms/Abbreviations Description 1 EMS Engine Management System 2 ECU Electronic Control Unit 3 CoC Centre of Competence 4 PT Powertrain 5 TML TATA Motors Ltd 6 DTC Diagnostic Trouble Code 7 MT Manual Transmission
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 6 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 1 Introduction This document contains the Procedures sequence to perform in case of component substitution or in case of configuration functions, i.e. the process to be followed whenever an ECU to be replaced or reflashed with new ECU software version or new software calibration version. 1.1 General Overview This document, will guide the service person/technician to correctly follow the steps in case of ECU/component replacement. It will also avoid the situation where vehicle failed to start due to the wrong procedure followed by technician. 1.2 Scope of the Document The scope of this document is limited to define the Component Replacement Procedure requirement. 1.3 Intended Audience The function owners, E&E CoC and ECM supplier are primary audience of this document. 1.4 IPR Ownership All Intellectual Property Rights that are directly or indirectly related to this document shall rest with CoC PT and related TML Internal Departments. 1.5 Reference Documents S No. Document Name Document No. Version No. Release Date - - - - - 2 Project Applicability The requirements specified in this document are applicable for all the MT variants of Q5 project which include Q501 which is a 5-seater application and Q502 which is a 7-seater application.
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 7 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 3 EMS Replacement Procedure Flowchart – In case Old ECM Communicates Figure 1: ECU Substitution Flow chart
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 8 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4 EMS ECU, Component Replacement Procedure 4.1 ECM - Engine Control Module (In case of old ECM communicates) Description: - See Figure 1: ECU Substitution Flow chart for more details. Routine concerning a component to be perform in case of component substitution. Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: IMA classification (for all injectors to be performed). IMA writing includes automatically ZFC1 procedure. IMA codes to be read from old ECM and written on new ECM. Read IMA values from Old ECM after entering into Extended Diagnostic Session: Command: 10 03 Command: $ 22 38 2F Write the Values in New ECM after entering extended Diagnostic Session and Taking Security Access: Command: 10 03 Command: $ 27 03 $ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02 command) Command: $ 2E 38 2F + 36 bytes Step 2: EEPROM DATA reading from old ECU after entering into Extended Diagnostic Session Command: 10 03 Command: $ 22 38 33 (for reading the data from EEPROM) $ 22 38 43 (for reading the data from EEPROM) Step 3: EEPROM DATA writing in the new ECU after entering extended Diagnostic Session and Taking Security Access: Command: $ 10 03 Command: $ 27 03
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 9 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. $ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02 command) Command: $ 2E 38 33 YY (for writing the data back into New ECM) $ 2E 38 43 YY (for writing the data back into New ECM) Where YY is data read from Old ECM Step 4: Proxi realignment / Variant COnfiguration to be done: Perform Variant Configuration Reset: Refer Section 4.21 – Variant Configuration Reset in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document for routine procedure detail. Perform the Variant Configuration after entering extended Diagnostic Session and Taking Security Access: Pick the 6 byte variant configuration value from PLM for specific vehicle variant and save in Tester. Command: $ 10 03 Command: $ 27 03 $ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02 command) Command: $ 2E FE AA YY Where YY is 6 Byte value [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is all procedures are completed and steps are performed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 10 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.2 ECM - Engine Control Module (In case of old ECM doesn’t communicates) Description: - See Figure 1: ECU Substitution Flow chart for more details Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Proxi realignment / Variant Configuration to be done; Perform the Variant Configuration after entering extended Diagnostic Session and Taking Security Access: Pick the 6 byte variant configuration value from PLM for specific vehicle variant and save in Tester. Command: $ 10 03 Command: $ 27 03 $ 27 04 XX XX XX XX (XX is the key calculated from the seed received through 27 02 command) Command: $ 2E FE AA YY Where YY is 6 Byte value Step 2: IMA classification (for all injectors to be performed). IMA writing includes automatically ZFC1 procedure. IMA codes to be read either from Server / from the Injector label (Entering to extended Diag. Session and Taking security Access is not required as in above step it has been done) Command: $ 2E 38 2F + 36 bytes Step 3: Below Routine has to be executed Lambda sensor UEGO-1 - ‘Exchange of Defective ECM’(LSU1 $ 02 05 XX) – Sub-function 01 Routine Execution Detail: Refer Section 4.2.1 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 11 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. Step 4: Below Routine to be executed “DPF 1 - Replacement of ECU and Old ECU is not communicating (Set EEPROM values for PFlt_CoRgn Exchange of ECU) ($ 02 06)” Routine Execution Detail: Refer Section 4.3.1 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 5: Below Routine to be executed “TVA DC Motor Test” Routine Execution Detail: Refer Section 4.11 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 6: Below Routine to be executed “EGR high pressure DC Motor Test” Routine Execution Detail: Refer Section 4.7 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 7: Below Routine to be executed “DPF Service Regeneration” Routine Execution Detail: Refer Section 4.3.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 8: Below Routine to be executed “VGT DC Motor Test” Routine Execution Detail: Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 9: Below Routine to be executed “VGT DC Motor Test” Routine Execution Detail: Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 12 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. Step 9: Engine Oil to be replaced with new Oil Step 10: “Reset of Blinking Engine Oil Pressure Lamp” IOCP Execution Detail: Refer Section 3.9 in ‘TML_PT_Q5_IOCP_EMS Requirement_2921 02 224 A1725_24June2017_V0.2’ document Engine oil parameters reset routine set to following parameters: - RDI 380C - Number of automatic reset procedure (Olil life reset with Examiner): it is increased of 1, - RDI 380D - Number of manual reset procedure (Oil life reset with manual procedure): it does not change, - RDI 380E - Odometer value at last automatic reset procedure (Olil life reset with Examiner): it is set to RDI 2001/RLI 03 value, - RDI 380F - Odometer value at last manual reset procedure (Oil life reset with manual procedure): it does not change , - RDI 3811 - Odometer value at the starting of change oil required indication: it does not change, - RDI 3810 - Remaining distance at exaust oil: it is set to MaxDistT calibrated value, - RDI 3813 - Remaining percentage at exaust oil: it is set to 100% value, - RDI 3818 - Oil life remaining from distance information: it is set to 100% value, - RDI 381A - Oil life remaining from oil exhaust information: it is set to 100% value, - RDI 381B - Oil life remaining from module coolant temperature and crankshaft revolutions: it is set to 100% value. [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 13 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.3 Single injector Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session and Security Access is taken 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: IMA classification ( for single injector), IMA writing includes automatically ZFC1 procedure. IMA codes can be read from old ECM and have to be written on new ECM. Command: $ 2E 38 2X + 9 bytes X: 9 for Injector Cylinder 1 A for Injector Cylinder 2 B for Injector cylinder 3 C for Injector Cylinder 4 Step 2: Below Routine to be executed “Reset Lambda sensor - 4.2.2 ‘Exchange of Injectors, Rail Pressure Sensor and MAF Sensor’ (LSU1 $ 02 05 XX) –Sub-function 02“ Routine Execution Detail: Refer Section 4.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 3: Below Routine to be executed “DPF injector reset (DPF5) – ‘Set EEPROM values for PFFlt_MassCalc Exchange of an emission relevant engine component’” Routine Execution Detail: Refer Section 4.3.2.3 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 14 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.4 All the injectors Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: IMA classification (for all injectors to be performed). IMA writing includes automatically ZFC1 procedure. IMA codes to be read from Server / Injector Label Command: $ 2E 38 2F + 36 bytes Step 2: Below Routine to be executed “Reset Lambda sensor - 4.2.2 ‘Exchange of Injectors, Rail Pressure Sensor and MAF Sensor’ (LSU1 $ 02 05 XX) –Sub-function 02“ Routine Execution Detail: Refer Section 4.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 3: Below Routine to be executed “DPF injector reset (DPF5) – ‘Set EEPROM values for PFFlt_MassCalc Exchange of an emission relevant engine component’” Routine Execution Detail: Refer Section 4.3.2.3 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 15 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.5 Closed coupled DPF + DOC Description: - See Figure 1: ECU Substitution Flow chart for more details Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “DPF Service Regeneration” Routine Execution Detail: Refer Section 4.3.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 2: Below Routine to be executed “Closed coupled DPF exchange ($ 02 07 11)” Routine Execution Detail: Refer Section 4.3.2.4 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 16 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.6 DPF pressure sensor Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Set EEPROM values for PFFlt_monitor Exchange DPF differential pressure ($020708)” Routine Execution Detail: Refer Section 4.3.2.1 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 17 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.7 Electrical VGT position sensor Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “VGT DC Motor Test” Routine Execution Detail: Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 18 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.8 Electrical VGT turbo compressor Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “VGT DC Motor Test” Routine Execution Detail: Refer Section 4.12 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 19 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.9 Engine oil replacement Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Engine Oil to be replaced with new Oil Step 2: “Reset of Blinking Engine Oil Pressure Lamp” IOCP Execution Detail: Refer Section 3.9 in ‘TML_PT_Q5_IOCP_EMS Requirement_2921 02 224 A1725_24June2017_V0.2’ document Engine oil parameters reset routine set to following parameters: - RDI 380C - Number of automatic reset procedure (Olil life reset with Examiner): it is increased of 1, - RDI 380D - Number of manual reset procedure (Oil life reset with manual procedure): it does not change, - RDI 380E - Odometer value at last automatic reset procedure (Olil life reset with Examiner): it is set to RDI 2001/RLI 03 value, - RDI 380F - Odometer value at last manual reset procedure (Oil life reset with manual procedure): it does not change , - RDI 3811 - Odometer value at the starting of change oil required indication: it does not change, - RDI 3810 - Remaining distance at exaust oil: it is set to MaxDistT calibrated value, - RDI 3813 - Remaining percentage at exaust oil: it is set to 100% value, - RDI 3818 - Oil life remaining from distance information: it is set to 100% value, - RDI 381A - Oil life remaining from oil exhaust information: it is set to 100% value, - RDI 381B - Oil life remaining from module coolant temperature and crankshaft revolutions: it is set to 100% value.
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 20 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.10 Rail pressure sensor Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Reset of ZFC values and IRS driving cycle counter” Routine Execution Detail: Refer Section 4.1 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 2: Below Routine to be executed “Reset Lambda sensor - 4.2.2 ‘Exchange of Injectors, Rail Pressure Sensor and MAF Sensor’ (LSU1 $ 02 05 XX) –Sub-function 02“ Routine Execution Detail: Refer Section 4.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 21 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.11 Air Flow meter Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Reset Lambda sensor - 4.2.2 ‘Exchange of Injectors, Rail Pressure Sensor and MAF Sensor’ (LSU1 $ 02 05 XX) –Sub-function 02“ Routine Execution Detail: Refer Section 4.2.2 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 22 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.12 Lambda sensor Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Exchange of Lambda Sensor Unit $02 05 03” Routine Execution Detail: Refer Section 4.2.3 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 23 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.13 EGR high pressure DC Motor Description: - See Figure 1: ECU Substitution Flow chart for more details Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “EGR high pressure offset reset and activation of the learning ($ 02 0F)” Routine Execution Detail: Refer Section 4.5 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document Step 2: Below Routine to be executed “EGR high pressure DC Motor Test” Routine Execution Detail: Refer Section 4.7 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 24 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.14 Throttle Valve Actuator Substitution Type: COMPONENT Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “TVA DC Motor Test” Routine Execution Detail: Refer Section 4.11 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 25 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.15 Reset driven distance max Th2O warning lamp ON Substitution Type: FUNCTION Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Temperature warning lamp ON driven counter reset ($ 02 16)” Routine Execution Detail: Refer Section 4.10 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.]
Q5 Project –EMS ECU/Component Replacement Procedure Q5 Project – EMS ECU/ Component Replacement Procedure Doc No: 2921 02 224 A1730 Date: 24 July 2017 Revision: 0.1 Page 26 of 26 Prepared: Shashank Addala / Prasad M Checked: Prasad M Approved: Satishkumar P This document contains confidential information which is exclusive property of TML. The contents of this document shall not be reproduced, or conveyed, or given to third parties in any manner without the consent of TML. 4.16 Reset driven distance H2O in fuel lamp ON Description: - See Figure 1: ECU Substitution Flow chart for more details Substitution Type: FUNCTION Pre-Conditions: 1. ECU should be in Extended Diagnostic Session 2. Ignition ON (T15_st = 1) 3. Engine not running (NMotV = 0) 4. Gear in neutral position Procedure To Be Followed: Step 1: Below Routine to be executed “Water in fuel lamp ON driven distance counter reset ($ 02 15)” Routine Execution Detail: Refer Section 4.9 in ‘TML_PT_Q5_Routine Procedures_EMS Requirement_2921 02 224 A1724_5June2017_V0.2’ document [Note: Perform Ignition toggle (Ignition OFF and Ignition ON) once procedure is completed in EMS ECU.] END OF DOCUMENT
Q501 4 Cylinder MT Application DTC Troubleshooting Data Version: 0.1 Date: 21-Sep-2018 Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta Checked By: Yogesh Jadhav Approved By: Satish Kumar P Page: 1 of 1052 Copyright © TATA MOTORS Ltd. This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author. EMS Diagnostic Manual for QQ5 (2L Engine) EDC17C69 EMS ECU Document History Ver Date Author Details 0.1 21-Sep-18 Manish Gupta Initial Release
Q501 4 Cylinder MT Application DTC Troubleshooting Data Version: 0.1 Date: 21-Sep-2018 Prepared By: Mithi Prasad, Sarang Kulkarni, Manish Gupta Checked By: Yogesh Jadhav Approved By: Satish Kumar P Page: 2 of 1052 Copyright © TATA MOTORS Ltd. This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author. Change History Issue Section Change details
