BODY
17
4. Remove four mounting screws of glove box of
bottom side.
5. Remove hush Panel to access HVAC pipe
connection with Glove box. Disengage HVAC
pipe while pulling out Glove box.
6. Remove one mounting bolt of glove box, which
is inside of glove box.
7. Disconnect the electrical connection of glove
box lamp.
8. Take out the glove box assembly.
FITMENT
For fitment follow the reverse procedure of
removal.
