BODY
22
4.9. FRONT DOOR TRIMS
REMOVAL
1. Open the Door.
2. Pull out Pull cup Cap.
3. Remove mounting screw below Pull cup Cap.
4. Insert wedge pin and remove window-winding
switch from door pull outer.
5. Disconnect the window winding connection and
remove the switch.
6. Remove inner handle screw cap.
7.
Loosen and remove the mounting screw of
inner handle.
8. Insert plastic wedge pin and remove the door
trim.
NOTE
While lifting door trim, care should be taken such
that tree clips don’t get damage. Below image
gives the location of tree clips on door trim.
