BODY
23
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
“For Side door Rattling Noise, Door Latch and
striker setting need to be done & maintain 1 mm
under flush condition.”
4.10. DOOR INNER LOCK HANDLE
REMOVAL
1.
Remove the door trim.
(For procedure refer
door trim removal process.)
2.
Remove inner handle screw cap.
3.
Loosen and remove the mounting screw of
inner handle.
4.
Remove one snap and two hooks located
behind the front door inner handle lever.
5.
Slide the Housing in horizontal / X direction
towards vehicle front and remove the lever with
Housing assembly from Door Inner panel.
