4.6. FRONT BUMPER
FRONT BUMPER REMOVAL (NEXON BS VI)
1. Open the bonnet.
2. Remove clips M6 on Front Bumper.
3. Remove ST 4.8X16 Screws on Front Bumper
from LH and RH sides.
4. Remove Flange Screw M6X20 and ST 4.8X16
from bottom side of Bumper.
5. Disconnect Fog Lamp Electrical Connection.
From LH and RH Sides.
6. Take out Front Bumper assembly from
Vehicle.
FRONT BUMPER ASSEMBLY
Follow the reverse procedure of Front Bumper
Removal
