7. Remove combination switch assembly and
ignition switch assembly (For procedure refers
combination switch and ignition switch removal
process in Electrical section.)
8. Remove two upper steering column and lower
steering column mounting nuts.
9. Disconnect the electrical connection.
10. Remove music system (If applicable). (For
procedure refer music system removal process
in Electrical section).
11.Remove floor console assembly. (For
procedure refer floor console removal process).
12. Pull out at end cover LH side
13. Remove ‘A’ pillar upper and lower trim. (For
procedure refer ‘A’ pillar trim removal process.)
14. Remove two mounting screw near ‘A’
pillar.(LH,RH)
15. Open the Bonnet.
16. Pay out seven Grommet pin and pull out
plenum cover.
17. Remove Front Wiper (For procedure refers
Front Wiper removal process in Wiper section.)
