BODY

18

4.5. SIDE AIR VENTS

REMOVAL

1. Carefully Pull out the dashboard mid panel RH

side

2. Remove three screw at RH side Air vent.

3. Pull out end cover LH side.

4. Remove one screw at dashboard mid panel &

take out.

5. Remove three screw at LH side Air vent.

FITMENT

For fitment follow the reverse procedure of

removal.
