1.5L REVOTORQ ENGINE
121
11.Remove all the electrical connections of the
HP pump.
12.Disconnect the fuel line connection of the HP
pump. Close the open fuel lines with suitable
plug to avoid spillage of fuel.
13.Disconnect the fuel line connection between
fuel rail and HP pump.
14.Loosen and remove the mounting bolts and
take out the H.P. pump assembly.
FITMENT
Follow the reverse order of removal procedure.
