1.5L REVOTORQ ENGINE

125

17. Remove A-mount support bracket.

18. Fit LH and RH engine mounting bracket to

engine.

SPECIAL TOOL



RH Mounting Bracket -:

5438 5890 2401

SPECIAL TOOL



LH Mounting Bracket -:

5424 5890 2403

19. Safely lift the engine with the help of crane

and fix it on overhaul stand 5425 5890 0605
