1.5L REVOTORQ ENGINE

118

4. Loosen and remove the mounting bolts on the

alternator support brackets.

5. Take out the alternator.

6. Loosen and remove the mounting bolts of the

alternator support bracket and take out the

bracket.

FITMENT

Follow the reverse order of removal procedure.

K. COMPRESSOR MOTOR REMOVAL AND

REFITMENT

REMOVAL

1. Remove the compressor belt.

(For removal

procedures refer compressor and alternator

belt replacement).

2. Disconnect the electrical connection of the

compressor.

3. Remove the suction and discharge hose of the

compressor.
