1.5L REVOTORQ ENGINE
117
5. Disconnect the electrical connection to the
starter motor.
6. Loosen and remove the bottom mounting
bolts of the starter motor.
7. Take out the starter motor.
FITMENT
Follow the reverse order of removal procedure.
J. ALTERNATOR MOTOR REMOVAL AND
REFITMENT
REMOVAL
1. Remove the RH side splash guard.
(For
removal procedures refer body section).
2. Remove the alternator belt.
(For removal
procedures refer compressor and alternator
belt replacement).
3. Remove the electrical connections of the
alternator.
