TRANSAXLE TA6300
37
12. Remove mounting screw of rear cover & take
out rear cover.
13. Remove Oil Seal of drive shaft.
14. Remove DETENT ASSY (SHIFTER SHAFT)
as shown & take out housing, Rear half.
15. Remove Hex FL bolt M8X25 for Reverse Idler.
16. Remove H/FL SCREW M8X12 & take out
stone guard bracket.
17. Remove hex screw M6X18 & take out clutch
speed sensor.
18. Remove snap ring on deep groove ball
bearing as shown
