TRANSAXLE TA6300
36
5. Remove all mounting Bolts & Nyloc nut from
top & bottom side from AMT kit as shown
6. Lastly take out AMT Kit from Transaxle.
7. Fix the mounting bracket 5425 5890 0603 &
5425 5890 0604 on work stand 5425 5890
0605 by using hex bolt
8. Mount transaxle face on mounting plate and fix
it by three hex bolts of M10 size.
9. Remove AMT top cover assembly.
10. Remove hex flanged screw holding release
lever on to release yoke and take out release
lever from release yoke.
11. Remove grooved pin & disconnect Clutch
release shaft & Clutch release Fork.
