TRANSAXLE TA6300
33
15. Drain the Transaxle oil through Drain Plug.
16. Remove stub axle ball joint Mounting &
Loosen Lower Control Arm on LH & RH side.
17. Remove ball joint (steering rack) from
steering knuckle from both sides.
18. Remove vertical link mountings on
suspension rod for both RH & LH sides.
19. Remove pre silencer Assy with pipe, front &
outlet pipe as shown
20. Remove 3 allen bolt of intermediate shaft &
take out Drive shaft from driver side/Engine
side.
