SUSPENSION
37
5.8.3. PIVOT MOUNTING BRACKET AND BUSH EXPLODED VIEW
FIG. 58
SR. NO.
DESCRIPTION
01
ASSY TWIST BEAM WELDED STRUCTURE
02
BKT PIVOT MTG
03
ASSY PIVOT BUSH REAR TWIST BEAM
04
HEX FL BOLT
05
HEX FL NUT AM12X1.25
06
HEX FL BOLT
07
BKT PIVOT MTG
