1.05L REVOTORQ ENGINE
106
8. Remove EVRV Hose between EVRV and Air
Filter.
9. Remove EVRV Hose between EVRV and
Vacuum Line.
10. Remove Rubber Hose as shown.
11. Remove Assy. Vacuum Modulator.
12. Remove EGR Pipe assembly with gasket.
13. Remove Charge Air Pipe with gasket.
