321 / 1002
1.05L REVOTORQ ENGINE
110
13. Remove
glow plugs fitted on the cylinder
block using extended socket
.
14. Remove Crank Position Sensor.
iii. REMOVAL OF EXHAUST MANIFOLD :
1. Remove exhaust elbow heat shield assembly.
2. Remove Oil feeder line between cylinder head
to turbocharger.
3. Remove closed coupled catalytic convertor
assembly with gasket.
