1.05L REVOTORQ ENGINE
107
14. Remove Assy EGR Valve with gasket.
15. Remove Elbow with gasket (for EGR Valve)
from cylinder block.
16. Fit LH and RH engine mounting bracket to
engine.
SPECIAL TOOL
RH Mounting Bracket -:
5401 5890 24 02
SPECIAL TOOL
LH Mounting Bracket -:
5424 5890 24 03
17. Mount the engine on overhauling stand.
