1.05L REVOTORQ ENGINE
112
10. Remove oil filter body using special tool.
SPECIAL TOOL
Spanner for Oil Filter -: 2779 5890 18 01
11. Remove Oil cooler assembly with adaptor.
12. Remove oil pressure switch sensor.
13. Remove adaptor with gasket which is
connected between crankcase and oil cooler.
14. Remove thermostat cover.
15. Remove the thermostat assembly.
