1.5L REVOTORQ ENGINE
130
v. REMOVAL OF EVRV AND THERMOSTAT
1. Disconnect all the vacuum pipes connected to
the EVRVs.
2. Loosen and remove the mounting fasteners to
remove both the EVRVs.
3. Remove the mounting bolts of the EVRV
mounting bracket and take it out.
4. Remove the thermostat cover.
5. Remove the thermostat assembly from the
water box.
6. Remove the temperature sensor mounted on
the water box.
7. Remove the mounting fasteners and take out
the water box assembly along with support
bracket.
