1.5L REVOTORQ ENGINE
99
B. LNT+CDPF
REMOVAL
1. Remove front exhaust pipe.
(Refer ‘Exhaust
assembly front with pre-silencer).
2. Remove the mounting bolt of the LNT support
bracket mounted on the engine.
3. Remove the engine cover
.
4. Remove the catcon support bracket.
5. Loosen and remove the mounting fasteners
and disconnect the catcon assembly from the
turbocharger.
6. Remove the turbocharger assembly from
below.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
Flushing operation for cleaning the catalytic
converter should be done by directing dry
compressed air draft in the direction of
catalytic converter inlet, after removing it
from the vehicle.
