1.5L REVOTORQ ENGINE
105
4. Remove the battery clamp and take out the
battery from the vehicle.
5. Remove the battery tray.
6. Remove fuse box mounting bracket bolts and
set the assembly aside for accessibility.
7. Remove the spring band clip and disconnect
the radiator hose of the thermostat.
8. Remove the mounting bolts of the EVRV
bracket and set aside bracket along with
EVRV.
