1.5L REVOTORQ ENGINE
95
33. Remove the mounting bolts of the exhaust
pipe front and disconnect the pipe.
34. Disconnect the electrical connection of engine
wiring harness and the main vehicle wiring
harness.
35. Remove front two tyres.
36. Disconnect the left and right drive shafts from
the vehicle.
(For removal procedures refer
Transaxle section).
37. Disconnect the ground wire on the gear box.
38. Use suitable belt/chain to fix a zip crane to the
engine lifting hooks located at front and rear
of the engine.
39. Raise the crane slightly up until very light
pressure is applied to the engine.
40. Loosen and remove the “C” mount assembly
mounting fasteners. Tilt back the mount
assembly.
