TRANSAXLE TA6300
29
11. Remove Assy. battery negative or earthing
cable from gear box as shown
12. Remove stub axle ball joint Mounting &
Loosen Lower Control Arm on LH & RH side.
13. Remove ball joint (steering rack) from
steering knuckle from both sides.
14. Remove vertical link mountings on
suspension rod for both RH & LH sides.
15. Remove starter motor connection & its three
mountings & take out starter motor.
16. Drain the Transaxle oil by removing Drain
Plug.
