TRANSAXLE TA6300
28
9 REMOVAL OF TRANSAXLE FROM
VEHICLE (FOR PETROL VERSION):
1. Park vehicle on forepost.
2. Remove the +ve & -ve battery connection.
3. Remove Battery mountings & take it out.
4. Remove Battery Tray as shown
5. Remove Translink cable or AMT coupler.
6. Remove ECU connection & also loosen its
mountings.
7. Take out Bracket mounted on AMT Kit as
shown.
8. Lossen wiring Harness around Transaxle
AMT.
9. Remove splash guard & also remove mud
liner inner front LH side.
10. Remove four mountings & take out tyres on
LH & RH side as shown
