1760 / 1906
BODY
25
III. GLOVE BOX:
REMOVAL:
1. Remove the top utility bin. (For procedure refer
top utility bin removal process.)
2. Open the glove box flap and remove the
stoppers with two hinge pins from both ends.
3. Loosen and remove three mounting screws of
HVAC cover.
ASSEMBLY:
For assembly press the glove box assembly
against the dashboard.
IV. SIDE AIR VENTS
REMOVAL
1. Remove the upper cover of steering column
from RHS.
2. Pull out the side air vent from RHS.
Follow the same procedure on the other side but
first remove the top utility bin.
FITMENT
For fitment follow the reverse procedure of
removal.
