BODY
28
5. Remove the Mud flap.
6. Remove the fasteners of panel wheel arch
inner.
7. Remove all the clips and take out the liner front
wheel house outer from the vehicle.
8. Loosen and remove (M5 hexagonal flange)
nuts from the front wheel arch cladding
assembly from LH and RH side.
9. Remove the front wheel arch cladding support
bracket LH and RH side.
10. Loosen and remove two mounting screws,
access the screws from the wheel arc end.
Follow the same procedure at other end.
