BODY
31
10. Loosen and remove mounting bolts which are
in the rear cabin area.
11. Lower the bumper and disconnect the reverse
parking electrical 4 connections and separate
the bumper.
12.
Pull out the rear bumper seal finisher.
ASSEMBLY:
For assembly follow the reverse procedure of
removal.
G. DOOR
I.
FRONT DOOR
REMOVAL:
1. Loosen and remove mounting screw and take
out the bonnet release lever.
2. Remove the trim behind the bonnet release
lever.
3. Disconnect the wiring harness and door
electrical connections.
4. Remove the door trim.
(For procedure refer
door trim removal.)
