BODY
24
II. TOP UTILITY BIN:
REMOVAL:
1. Open the flap and remove two mounting
screws.
2. Pull out the top utility bin.
3. Pull out the HVAC hose which is connected to
the top utility bin and remove the adapter from
the utility bin.
4. Disconnect the glove box lamp switch
electrical connection.
5. Disconnect the electrical connection of Glove
box lamp and take out the Top utility bin.
ASSEMBLY:
For assembly follow the reverse procedure of
removal.
