BODY
29
11. Removal of three mounting screws & washer
from the mid area of the bumper.
12. Disconnect fog lamp connectors and remove
the bumper by unsnapping at 4 locations (i.e.
Bumper holding bracket LH/RH at fender
location and Head lamp mounting bumper
support bracket LH/RH
).
13. Remove Grill from the bumper by removing the
twelve screws on inner side of the bumper.
14. Remove the Chrome line by unscrewing the 7
screws.
ASSEMBLY:
For assembly follow the reverse procedure of
removal.
