13. Remove the three screws from bezel end of
floor console assembly.
14. Remove the floor console assembly rear
console cover by unsnapping.
15. Remove the two fasteners to remove arm rest.
16. Remove the electrical connector of rear
console cover.
17. Remove the two fasteners at rear cover side.
18. Remove the two fasteners below the arm rest.
19. Remove tree clip of Parking Sensor
20. Remove parking lever cover.
