328 / 1002
1.05L REVOTORQ ENGINE
117
13. Remove the crankshaft gear.
14. Remove the back timing cover.
15. Remove Oil pump assembly with oil seal.
16. Loosen the mounting bolts from flywheel.
Remove flywheel locking pin. Remove
Flywheel.
SPECIAL TOOL
Flywheel Locking Pin -:5401 5890 06 04
17. Remove crankcase rear cover with oil seal
