1.05L REVOTORQ ENGINE
115
4. Remove balance shaft bearing cap.
5. Remove balancer shaft.
6. Remove the cap screw. Take out the ladder
frame.
v. REMOVAL OF TIMING BELT :
1. Insert the flywheel locking pin to lock the
flywheel.
SPECIAL TOOL
Flywheel Locking Pin.-: 5401 5890 06 04
2. Remove the vibration damper pulley.
3. Remove the front timing cover.
