BODY
28
9.9.5 SPEAKAR GRILL SERVICING
1. Insert the wedge pin to remove the speaker
grill.
2. Drag it along the arrow direction to remove
the speaker grill.
ASSEMBLY
1. Position the speaker grill properly and press
fit it.
9.10.6 TWEETER SERVICING
1. Pull the speaker grill along with tweeter
upwards.
2. Remove the wire harness connections and
remove the tweeter.
3. Remove screws as shown in fig and remove
tweeter.
ASSEMBLY
1. Fix the tweeter by screws.
2. Connect the wiring harness connection
3. Press fit the assembly.
