9.9.13 CLIMATE CONTROL MODULE FIXINGS

1. Remove fascia cover.

2. Disconnect the electrical connection of panel.

3. Unscrew the climate control module fixing

from the fascia cover.

4. Take out the control panel.

ASSEMBLY

1. Tighten the fasteners of climate control

module.

2. Connect the electrical connection of panel

3. Press fit the fascia cover
