BODY
32
9.9.11 GLOVE BOX SERVICING
1. By using Battery Angular tool, unscrew the
two bottom fixings.
2. By using Battery Tool, unscrew the five Top
inner fixings.
3. Press the Glove box bin towards inside to
unlock the locator.
4. Use Top Side Air vent Hole for pressing
Glove box bin.
5. Pull out the Glove box bin.
ASSEMBLY
1. Locate the glove box
2. Press fit the glove box in its position
3. Tighten the inner fasteners.
4. Then tighten the Bottom fasteners.
9.9.12 STEERING COLUM COVER SERVICING
1. By using Battery Pistol, unscrew the COVER
STEERING COLUMN from the Dashboard
Lower.
2. Pull it out in the arrow direction.
ASSEMBLY
1. Properly align the cover steering column with
the dash board and tighten the three
fasteners.
9.10.14 Removal & Refitment of Steering
9.10.15 R+R of Steering Nacelle
9.10.16 R+R of Steering Colum
9.10.17 Stalk module servicing
For above process Refer to Steering Section
