BODY
35
7. By using battery tool unscrew the fixing
fasteners of right side as shown in fig.
8. Remove trailing link bottom fixing screw.
9. Remove steering column from coupling.
10. Remove earthing points from cross car beam
support s shown in fig.
11. Remove earthing points from vehicle body
shown in fig.
12. Remove all wiring harness connections.
13. Remove cluster.
14. Remove dashboard central fastener.
15. Remove dashboard along with HVAC/FATC
and steering.
