BODY
34
9.9.14 REMOVAL OF DASH BOARD
1. Remove the A-PILLAR on LH and RH side.
2. Remove electrical connection.
3. Remove the glove box.
4. Remove end cover LH by using plastic
wedge.
5. By using battery tool unscrew the fixing
fasteners of left side as shown in fig.
6. Remove end cover RH by using plastic
wedge.
