ELECTRICAL
76
12.20 WINDOW WINDING MODULE:
FUNCTION:
The window winding operation is electrically
operated. The electrically operated window
winding facility is provided on some models. The
driver alone can control the closing and opening
of all the window glasses in addition to individual
occupant.
LOCATION:
Window winding switches are provided on RH
side front door. Separate individual switch is
provided on front door LH & rear RH / LH doors.
The switch will function when ignition key is
turned to’ ON’ position. For taking window glass
‘UP’, press and hold the switch towards position
marked , and for down, press towards position
marked .Do not press switch further when window
glass is atits extreme position. Do not operate
window glass frequently, otherwise Window
winding motor may get over heated and stop
working till it cools down.
CONNECTION DETAILS
