ELECTRICAL
78
DIAGNOSTIC INFORMATION & PROCEDURE
WINDOW WINDING MODULE
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
One or more of the
window
winders not working
1. Fuse (30A) for the
respective
door loose/ blown under
cockpit LH
Replace the fuse
2. 2 pin Window Winding motor
Connector loose
Fit the connector properly
3. 6 pole WWM Console
switch
connector loose
Fit the connector properly
All Window winders
moving
slowly/not working at all
1. Battery discharged
Recharge the battery
2. WMM Console master
switch
20 pole connector loose
Fit the connector properly
