ELECTRICAL
66
12.17 FASCIA SWITCHES
Apart from front & rear fog bulb switch, hazard
warning switch and rear heated window switch,
fascia switch panel also incorporates PAB
indication bulb and Seat belt reminder display.
1) FRONT FOG LAMP
2) REAR FOG LAMP
3) ECO/SPORT (DRIVE MODE SWITCHS)
1. FRONT FOGLAMPS (IF FITTED):
Front Fog Lamps are provided on front bumper to
provide improve divisibility in adverse weather
conditions to avoid accidents when visibility is
poor.
The front fog lamps can be switched ‘ON’ with
ignition and parking lamp ‘ON’ and can remain on
till the parking lamp is switched ‘OFF’.
2. REARFOGLAMPS (IF FITTED):
Rears Fog Lamps are provided on rear bumper to
provide improve divisibility in adverse weather
conditions to avoid accidents when visibility is
poor.
The rear fog lamps can be switched ‘ON’ with
ignition and parking lamp
‘ON’ and can remain on
till the parking lamp is switched ‘OFF’.
3. ECO/SPORT
(DRIVE
MODE
SWITCHS)
(Applicable for Revotron 1.2T with manual
transmission)
3 drive modes are provided. These modes can be
used to adjust certain characteristics of engine &
vehicle performance.
Drive mode selection switches are provided on
dashboard fascia to
activate the programs.
Selected drive mode will be displayed on DIS
provided in Instrument cluster.
NOTE:
’CITY’ is the default mode and will not be
displayed.
Select the desired mode as per driving
feasibility.
Drive mode switches are provided on the
dashboard fascia to activate the desired Mode.
SwitchOperation
Current Mode NewMode
ECO switch is
Pressed
CITY
ECO
ECO switch is
Pressed
ECO
CITY
SPORT switch is
Pressed
ECO
SPORT
SPORT switch is
Pressed
CITY
SPORT
SPORT switch is
Pressed
SPORT
CITY
ECO switch is
Pressed
SPORT
ECO
