ELECTRICAL
86
S.
NO
FUNCTIONALIT
Y
ACTIVATION CONDITION Button
1
(Lock)
Button 2
(Approach)
Buttton
3
(Unlock)
Short
press
Long
press
Short
press
Long
press
Short
press
Long
press
1
Lock
Vehicle is in unlock state
and Lock button is pressed
on RKE.
×
2
Double Locking Vehicle is in Lock state and
Lock button is pressed,
within Double lock Timer.
×
3
Vehicle Seek
Vehicle is in Lock state and
Lock button is pressed,
after the lapse of Double
lock timer.
×
4
Window
closing/window
up
RKE Lock button is kept
pressed for >2secs.
×
5
Approach light
ON
Approach light is in OFF
state and Approach light
button is pressed and
released. (Other
preconditions as per BCM
requirements to be
satisfied).
×
6
Approach light
OFF
Approach light is in ON
state and Approach light
button is pressed and
released. (Other
preconditions as per BCM
requirements to be
satisfied).
×
7
Unlock
Vehicle is in Lock state and
Unlock button is pressed on
RKE. Only Driver door will
be unlocked if Two Stage
Unlocking is enabled on
BCM. (As per EOL
configuration).
×
8
Second Stage
Unlocking
Driver door is in unlock
state by earlier Unlock
request, and Unlock button
is pressed second time.
×
9 Window
Opening /
Window Down
RKE Unlock button is kept
pressed for > 2secs.
×
10
Tailgate Open Tailgate is in Lock state
and Approach button is
kept pressed for >= 2 secs.
×
11 Force Panic
Lock and Unlock button are
pressed simultaneously.
×
×
×
