ELECTRICAL
72
POSITION DETAIL DESCRIPTION
C15 USB1GND
C16 Aux In Shield
C17 Aux In Detect
C18 Aux In Com
C19 Aux In_R
C20 Aux In_L
PIN DETAILS OF B:
POSITION DETAIL DESCRIPTION
1 NC
2 GND
3 Remote_TFT_EN
4 RVc Video Signal
5 RVc Video Sheild
6 RVC_PWR
7 Aux In Video Shield
8 Aux In Video Sig
9 NC
10 NC
11 ProtectGPIO2
12 ProtectGPIO1
13 RVc Video GND
14 USB2_5V
15 USB2GND
16 Aux In Video GND
PIN DETAILS OF C:
POSITION DETAIL DESCRIPTION
1 USB2_D-
2 USB1_D-
3 USB2_D+
4 USB1_D+
SPECIFICATIONS:
 Operating voltage: 9-16V
 Test voltage: 13.5V
 Operating current: 1.5A 4×0.5@4 ohm load
 Maximum current: 15A
 Operating temperature: -30ºC-70ºC
 Storage temperature: -40ºC-90ºC
 Leakage current: 0.6mA
