ZEST AND BOLT - page 1034

ELECTRICAL
67
NOTE:
CITY is the default mode. If both switches
pressed simultaneously last mode is retained.
DriveMode
Desired performance
PETROL
ECO
Optimum engine Torque & Power for Fuel efficient
performance*
CITY (default)
Increased engine Torque & Power for balanced
performance
SPORT
Max engine Torque & Power to sporty performance
FASCIASWITCH PANEL REMOVAL
1. Carefully pull out fascia switch cover.
2. Disconnect electrical connection from the
fascia switch assembly.
3. Remove four screws from the fascia switch
assembly.
4. Take out the fascia switch panel.
INSTALLATON:
1. Fit the fascia switch panel on fascia cover.
2. Tight the mounting screws of fascia switch
panel.
3. Fit the electrical connection in fascia switch
panel.
