ELECTRICAL
70
12.18 INFOTAINMENT SYSTEM: ( If
fitted)
Infotainment system is provided on the centre
console. To operate this system, please refer
infotainment manual, which is provided along with
the Owner’s Manual.
USB/AUX PORT LOCATION
1. USB and AUX ports are fitted below the Fascia
switch.
USB:
External memory devices like memory sticks / Pen
Drives, I-Pods can be connected for playing music
tracks stored in these devices through the vehicles
music system.
AUX:
AUX port provided to connect audio input devices
for playing music tracks stored in the devices
through vehicle’s speakers.
SPEAKERS:
Speakers and tweeters are provided on models with
infotainment system. Provisions are given for music
system and speakers on models without
infotainment system.
ANTENNA:
Antenna is located on the roof, above the front
windshield glass on selected models. In some
models provision is given for fitment.
INFOTAINMENT SYSTEM LAYOUT AND PIN
DETAILS
