280 / 1119
1.5L REVOTORQ ENGINE
92
14. Drain the engine oil by removing the drain
plug into a suitable container.
15. Drain the engine coolant by removing drain
plug into a suitable container.
16. Remove the bottom LH and RH guard.
17. Remove the drain plug from the transaxle.
Drain the transaxle oil from the vehicle.
18. Recover A/C compressed gas using suitable
recovery unit.
19. Remove the battery tray.
20. Disconnect electrical connection to the t-map
sensor. Remove the mounting bolts and
clamp to remove the air filter assembly.
