7. Remove washer insulator.

8. Remove snap ring.

NOTE

After removal of snap ring do not reuse the same

at the time of assembly replace the snap ring with

the new one.

9. Remover entire clutch pack from the output

shaft.

D. CHAIN DRIVE

1. Remove snap ring from the output shaft.

NOTE

After removal discard the snap ring and use new at

the time of assembly.
