HEXA

TOD

9. Pull out the TOD along with the movable

support

(placed in step7)

from the Gearbox and

then lower it carefully.

FITMENT

For fitment follow reverse procedure of removal.

B. TOD ELECTRONIC CONTROL UNIT

(ECU)

REMOVAL

1. Switch Off Ignition.

2. Disconnect the battery negative.

3. Pull out the carpet from the firewall end so as to

have access to the TOD ECU on Co-driver end.

4. Disconnect the electrical connection from the

TOD ECU.

5. Loosen and remove two mounting bolts and

take out the ECU from the vehicle.

FITMENT

For fitment follow reverse procedure of removal.

C FASCIA SWITCH

NOTE

For on vehicle repair details of Fascia switch refer

switch section in electrical group.
