1770 / 1906
BODY
35
V.
FRONT DOOR LATCH:
REMOVAL:
SR.
NO.
DESCRIPTION
1
Cable between inner handle to latch
2
Cable between pop up knob to latch
3
Link between lock barrel to latch
4
Link between outer handle to latch
5
Latch
1. Remove the door trim.
(For procedure refer
door trim
removal
process.)
2. Disconnect electrical connector at the latch
end.
3. Push the pop knob in downwards so as to in
lock position to have better access to remove
the links.
4. Disconnect the inner handle cable from the
inner door handle and bracket.
5. Disconnect the pop up knob cable from the
bracket.
6. Disconnect the link between lock barrel and
latch from the lock barrel end.
7. Disconnect the outer handle link from the outer
handle end.
