BODY
34
IV.
FRONT OUTER DOOR LOCK
REMOVAL:
1. Remove the door trim.
(For procedure refer
door trim
removal
process.)
2. Take out the plug and remove the mounting
screw of front door lock.
3. Take out the cap of outer door handle.
4. Take out the lock barrel.
5. Remove the gripper handle.
6. Remove the door outer handle screw.
7. Disconnect the links of outer door handle and
lock barrel and take out the outer door handle
bracket from the door shell.
ASSMBLY:
For assembly follow reverse procedure of removal.
